Universal VTT import and export

Documentation · Português · Map Builder

Use Universal VTT to bring a finished map, its grid, walls, doors and lights into Gravewright, or to download an interchange copy of a native scene. Only a campaign GM can import or export. Imported scenes start visible only to the GM and do not replace the scene currently broadcast to players.

Choose the import path

The Builder offers two different import actions:

For an image, choose Library → Import → Import ready-made map, or the same action in Settings or Saved projects. Upload an image (up to 25 MB) or choose an existing campaign image, set the width and height in cells and the cell size, then choose Use map image. The image fills the map beneath its layers. Project changes save automatically; Generate scene or Update scene applies them to the game. See Import a finished map for replacement, removal and Undo/Redo.

A Universal VTT import cannot reconstruct the source map's brush strokes, individual assets or Builder layers from its flattened background. Opening this importer from the Builder still creates a separate native scene.

Import a Universal VTT scene

1. In Scenes, choose New scene → Import Universal VTT. To import into a scene folder, start the new-scene action from that folder. The same importer is available under Saved projects → Import Universal VTT in the Builder.

2. Select the Universal VTT file and check Scene name. Selecting a file fills an empty name from its filename; you can change it. Names must contain 1–120 characters. The dialog has no grid or lighting controls: those values come from the file.

3. Choose Import scene and wait for the result. The import dialog cannot close while this request is running.

4. Read the warnings, then choose Close. Warnings describe the scene already created; there is no approval or preview step before creation.

5. Inspect the scene in Scenes. Check grid alignment, wall openings, door states and lighting with the native scene tools before activating it for players.

The destination folder comes from the action that opened the importer; there is no folder picker inside the dialog. The folder must belong to this campaign. The background is stored as scene tiles, while walls, doors and lights remain editable native objects. Import creates no Map Builder project and does not overwrite an existing scene or Builder draft.

Read the import warnings

Warnings indicate an imported approximation, rather than a failed import:

Recover from an import error

If validation fails, read the message, correct the name or source file and choose Import scene again. Invalid files, unsupported images or excessive geometry do not leave a partially created scene. If the file contains lights and the installation reports Dynamic lighting is disabled, the operator must enable that feature or provide a file without lights.

If the connection fails, the server may already have completed the import. Keep the same dialog open, leave the file and name unchanged and choose Import scene again: the dialog reuses the operation's request UUID and the server returns the original result instead of creating another scene. There is no separate Retry button or automatic retry.

Changing either field or reopening the dialog starts a new operation. After closing the dialog or reloading the page following an uncertain result, check Scenes before importing again, to avoid creating a second scene.

Export the current scene

If you are working in the Builder, first finish Generate scene or Update scene. Automatic saving stores the project; exporting reads the native scene already applied to the game, including its subsequent native edits. A saved project or an unpublished draft is not the export source.

1. Right-click the scene in Scenes and choose Export Universal VTT.

2. Choose Prepare export and wait for preparation to finish.

3. Review the warnings, then choose Download Universal VTT to save a .uvtt file.

The prepared download is a snapshot. If the scene changes after preparation, close and reopen the exporter to prepare a new copy. You can close the export dialog while preparation is pending. Export does not modify the scene, project, receipts or stored artwork.

What the download keeps

GM-only image artwork is omitted. Locks, secret-door presentation, height ranges and separate movement, vision, light and sound barrier channels are not preserved. A secret door's geometry can still be present: check the file before sharing it with players.

Blueprints, variables, timers, presence regions, tokens, cards, markers, journal permissions, particles, shaders, fog, drawings and audio are not transferred. Disabled lights are omitted. The file does not restore a Builder project or campaign state, and another application's interpretation may differ. Keep the original project and use the installation's backup process for recovery.

If preparation fails, read the error before trying again. Missing or unreadable background tiles and exceeded composition limits prevent a complete export; the dialog does not offer a partial download.

Format and coordinate contract

The accepted container is JSON with numeric format: 0.2; the three supported filename extensions use this same contract. 0.2 is the interchange format version, independent of the Gravewright application version. Import requires an embedded, single-frame PNG or WebP image encoded as raw base64, not a data URL, file path or remote URL. Image metadata is removed; EXIF orientation is not applied to map coordinates.

Image dimensions must equal the rounded products of map_size and pixels_per_grid. For example, a 20 × 15-cell map at 70 pixels per cell needs a 1400 × 1050-pixel image. Object positions become (point - map_origin) × pixels_per_grid. Portal bounds determine door geometry; portal position, rotation and freestanding do not add separate native placement or behavior.

Colors accept six-digit RRGGBB or eight-digit AARRGGBB, optionally prefixed with #. Light alpha multiplies the clamped intensity. For example, color 80ff0000 and intensity 1 produce a red light with intensity approximately 0.502. Imported range becomes the dim radius, with a zero bright radius.

Limits and authorization

These limits apply in addition to installation configuration:

Configured upload bytes, image dimensions and tile-count limits may be lower. Duplicate JSON keys, invalid numbers or base64, unsupported or animated images, inconsistent dimensions and excessive geometry are rejected. Uploaded filenames never become server paths. Artwork used during export must belong to the campaign; generated masks must also belong to that exact scene.

Players and streamers cannot import or export. Import rechecks GM membership and folder ownership before committing, records a request receipt and removes newly stored tiles if the operation fails. The same request UUID with the same file, name and folder replays the original result; a changed payload with that UUID is rejected as a conflict. Import through the public interface never activates the new scene for players.

HTTP contract and implementation checks

• POST /api/containers/{campaign}/universal-vtt/import: multipart file, name, request_id and optional folderId; returns {scene, warnings, builderEditable: false}.

• GET /api/maps/{scene}/universal-vtt: returns {filename, document, warnings}. document is the downloadable UVTT JSON.

The service is universal_vtt.py, with GM-only HTTP views and the import/export dialog. Focused tests cover geometry, grid/ARGB conversion, current artwork, receipts, rollback, isolation and limits. The browser scenario covers the public modals, a lost-response retry, downloads, round trips and role boundaries. Use the isolated environments described in Testing.
